- Current dependence action
- Reliable ST / UT curve
- Refrigerator Overheat Protector
- Strong & Durable Material
- No Rust option for SPCC / SUS
- Reduce noise and prevent creep
- Other cooling system
SPECIFICATION
RATING
16Amps / 240VAC
32Amps
/ 115VAC
Temperature Range
Open 100¡É to 155¡É
Close 57 to 75
Tolerances
OPEN ¡¾5¡É / CLOSE ¡¾9¡É
Life Cycle
10,000 cycles
Contact Resistance
Less than 50m¥Ø¡¡
RATING
AC 125V 30A (UL)
AC 250V 15A (UL)
AC 115V 32A (VDE, CQC)
AC 240V 16A (VDE, CQC)
