HOME >PRODUCT > LGA



Feature

- 3-Point crown stamping contactor
- Perfect loading by all ball guide adapter
- Package to PCB direct contact
- Package warpage issue solution



Electrical
Contact self inductance 10nH maximum @ 50MHz
Contact resistance <50mΩ @ 10mA, 20mV
Insulation resistance >1,000mΩ @ 100VDC
Withstanding voltage 1,000VAC / 1minute
Current rating 0.9A

Mechanical
Contact force 12±3g·f
Temperature rating -55°C ~ +150°C
Cover actuation force MAX 5.2±1kg·f
Life cycle

Min. 10,000cycle (1cycle =load&unload)


Socket Size Pitch Max IC Size Full Matrix

26.0*28.0*17.0

0.35*0.35

16.0*17.0

43*43


* Common spec : 1cycle = load&unload
